Highly flexible, rugged, and equipped with three-pin, brand name connectors by NEUTRIK © – just like the audio cables in the 5-Star series, these cables also offer optimum performance. The cable material used complies with the AES/EBU standards for data communications.
Specifications:
- Type: DMX AES/EBU Cable
- Color: black
- Overall diameter: 6.4 mm +/- 0.1 mm
- Conductor area: 2 x 0.34 mm²
- AWG (American Wire Gauge): 22
- Conductor material: copper wire screen
- Composition of conductor: 19 x 0.15 mm
- Screen material: bare copper, OFC
- Screen: spiral wound
- Conductor resistance: 53 Ohm / km
- Capacity: < 63 pF/m
- Overall jacket material: PVC
Plugs:
- Model name NC3FXX
- Manufacturer: Neutrik
- Product type: XLR Plug
- Type: straight
- Number of poles: 3
- Gender: female
- Cable diameter: 3.5 – 8 mm
- Colour marking: –
- Contact surface: Silver
- Connection type: Solder contact
- Colour: Silver
- Housing: Cast zinc
- Clamping sleeve: POM
- Dimensions (L x Ø ): 71.5 x 19.2 mm
- Model name NC3MXX
- Manufacturer: Neutrik
- Product type: XLR Plug
- Type: straight
- Number of poles: 3
- Gender: male
- Cable diameter: 3.5 – 8 mm
- Colour marking: –
- Contact surface: Silver
- Connection type: Solder contact
- Colour: Silver
- Housing: Cast zinc
- Clamping sleeve: POM
- Dimensions (L x Ø ): 68,1 x 20,4 mm
