DISPLAYCOBTRWDFC is the track-mount version of DISPLAYCOBFC, featuring elegant white housing and Wireless DMX module on board for the remote control of the luminaire, beeing an innovative and perfect solution for installation in commercials, showrooms, museums and churches. DISPLAYCOBTRWDFC employs 60W COB LED source RGB/FullColor, combined with a special parabolic reflector built in aluminium which develops an extremely bright and homogeneous output and interchangeable lens system to switch from 60° (incl.) to 30° (incl.) and 15° (opt.)
Features:
60W RGB COB LED Source for limitless vivid colors
Track-adaptor (EUTRAC compatible) included
Wireless DMX on board for cable-free remote control over application on standard tracks
Interchangeable optics: 60° (incl.), 30° (incl.), 15° (optional)
Superior color mixing and emulation of the white spectrum
Barndoors and filter frame accessories available
LIGHT SOURCE
Source:
60
W
COB RGB Led
Luminous Flux:
2055
lm
Lux:
(30°) 480
lux
@3m Full
Lux:
(60°) 178
lux
@3m Full
Source Life Expectancy:
>30.000 h
OPTICS
Beam Angle:
60
°
Field Angle:
80
°
Lens Type:
Dichroic parabolic reflector in combination with HD fresnel lens
Additional Optics:
30° (inc) – 15° (opt)
COLOR SYSTEM
Color Mixing:
RGB/FC
White Presets:
3200~10000
K
Color Wheel:
Virtual color wheel with presets
Macros:
Built-in white presets
DYNAMIC EFFECTS
Static Color Mode:
Selection of static color
Manual Color Mode:
Manual adjustment of color
Auto Mode:
Built-in programs with execution speed adjustment
BODY
Body:
Sturdy die-cast aluminium body conceived for long-time durability
Body Color:
White
CONTROL
Protocols:
DMX512
Dmx Channels:
3/5/8
ch
W-DMX:
Included, Wireless Solution receiver
Display:
Black OLED high resolution display
Firmware Upgrade:
Yes, via USB-DMX interface (UPBOX1) not included
Master/Slave:
for synchronized operation of more units linked in a chain
ELECTRONICS
Dimmer:
Linear 0~100% electronic dimmer
Dimmer Curves:
4
Different dimming curves available
Strobe/Shutter:
1-28
Hz, electronic
Operating Temperature:
-10/45°
Flicker:
Flicker free operation
ELECTRICAL
Power Supply:
100-240V u2013 50/60Hz
Power Consumption (at 230V):
75
W
Power Consumption (at 120V):
70
W
PHYSICAL
Signal Connection:
5p in/out
Power Connection:
Track Adaptor (EUTRAC compatible)
IP:
20
Cooling:
Natural cooling of the peculiar chassis and to absence of fans
Suspension And Fixing:
Track-Adapter included for suspension and fixing
Dimensions (WxHxD):
166x118x290
mm
Weight:
1,85
Kg
DISPLAYCOBL30 1x60W RGB/FC COB LED projector, 60°, IP20, 63W, 1,85kg, track, WDMX
